Vertical CNC lathe machine China factory direct sale
| Specifications | Unit | VTC700 |
| Max.turning diameter of workpiece | mm | 700 |
| Max.rotating diameter | mm | 650 |
| Hydraulic chuck diameter | mm | 500 |
| Spindle speed | rpm | 500-1000 |
| Cutting feed speed | mm/min | 0.1-1000 |
| Tool post vertical travel | mm | 550 |
| Tool post horizontal travel | mm | 420 |
| X axis fast traverse speed | mm/min | 15000 |
| Z axis fast traverse speed | mm/min | 12000 |
| Tool post type | 4 station electric tool post | |
| Tool shank size | mm | 32×32 |
| Main motor power | 11/15kW
(low speed large torque output 210NM ) |
|
| Feed motor power/torque | kw | 2.4KW/15N.M |
| Coolant pump motor power/liquid | W | 250W 40L/min |
| Positioning accuracy | mm | 0.03mm |
| Repeat positioning accuracy | mm | 0.015 mm |
| Weight | kg | Around 5800kg |
| Dimension | mm | 2250×1960×2650 |
This machine tool is an automated CNC machining machine tool. It is used to process the inner and outer cylindrical surfaces, conical surfaces, end faces, grooving and chamfering of parts. It is especially suitable for automotive brake hubs, wheel drums, clutch pressure plates, and flywheels. Processing of shells and other parts.
