Heavy-duty vertical CNC lathe available for immediate purchase with cutting-edge technology
| SPECIFICATIONS | Units | VTC650 |
| Max. Swing diameter | mm | 650 |
| Max. Turning diameter | mm | 550 |
| Spindle Model | A2-8 | |
| Diameter of spindle bearing | mm | 120 |
| Spindle speed range | rpm | 50-1250 |
| Spindle output torque | nm | 475 |
| Chuck diameter | 〞 | 15〞HYD |
| Turret type | ||
| Turret spec | 100 | |
| Tool size | mm | □25/φ40 |
| Turret travel X axis | mm | -375 |
| Turret travel Z axis | mm | 550 |
| Distance from Bottom of turret to up of chuck | mm | 0-550 |
| X/Z linear rails | 45 Roller | |
| Diameter of X/Z screw | mm | φ40 |
| X-axis rapid traverse | m/min | 15 |
| Z-axis rapid traverse | m/min | 12 |
| Cutting feeding | m/min | 0.1-5000 |
| X axis motor power/torque | Kw/nm | 2.4/15 |
| Z axis motor power/torque | Kw/nm | 2.4/15 |
| Main motor power/torque | Kw/nm | 15/18.5- 190 |
| Overall size (L*W*H) | m | 1.95*1.85*2.65 |
| Machine weight | kg | 5200 |
| Machine weight | kg | 8800 |
| Overall dimensions | mm | 2800*2000*3200 |
This machine tool is an automated CNC machining machine tool. It is used to process the inner and outer cylindrical surfaces, conical surfaces, end faces, grooving and chamfering of parts. It is especially suitable for automotive brake hubs, wheel drums, clutch pressure plates, and flywheels. Processing of shells and other parts.
